AWS CloudFormation Cheatsheet AWS CloudFormation Cheatsheet

Karandeep Singh

Jul 15, 2025 • 6 minutes

Summary

Quick-reference CloudFormation guide. Template sections, intrinsic functions, stack lifecycle CLI commands, change sets, drift detection, and error fixes.

CloudFormation is still my default for AWS-native infrastructure. No state file to babysit, and rollbacks come free. This is the reference I wish I had when I started: template anatomy, the intrinsic functions I actually use, and the CLI commands for the full stack lifecycle. For imperative AWS scripting I reach for boto3 instead, and config management after provisioning goes to Ansible.

Template Anatomy

Docs: Template anatomy, CloudFormation User Guide

AWSTemplateFormatVersion: '2010-09-09'   # only valid value
Description: App network layer

Parameters:        # runtime inputs
  EnvName:
    Type: String
    Default: dev
    AllowedValues: [dev, staging, prod]
  VpcCidr:
    Type: String
    Default: 10.0.0.0/16
    AllowedPattern: ^\d+\.\d+\.\d+\.\d+/\d+$

Mappings:          # static lookup tables
  RegionAmi:
    us-east-1: { Ami: ami-0abc1234 }
    ca-central-1: { Ami: ami-0def5678 }

Conditions:        # booleans evaluated at deploy time
  IsProd: !Equals [!Ref EnvName, prod]

Resources:         # the only REQUIRED section
  MyVpc:
    Type: AWS::EC2::VPC
    Properties:
      CidrBlock: !Ref VpcCidr

Outputs:           # values to display/export
  VpcId:
    Value: !Ref MyVpc
    Export:
      Name: !Sub '${EnvName}-vpc-id'

Other top-level sections: Metadata, Rules (parameter validation), Transform (AWS::Serverless-2016-10-31 for SAM, AWS::LanguageExtensions for Fn::ForEach).

Intrinsic Functions

Docs: Intrinsic function reference, CloudFormation User Guide

Function	Short form	What it does
`Ref`	`!Ref`	Parameter value or resource’s default ID (e.g. VPC ID, bucket name)
`Fn::GetAtt`	`!GetAtt Res.Attr`	Named attribute of a resource (`!GetAtt Db.Endpoint.Address`)
`Fn::Sub`	`!Sub '${Var}-x'`	String interpolation of params, resources, pseudo params
`Fn::Join`	`!Join [':', [a, b]]`	Join list with delimiter
`Fn::If`	`!If [Cond, valTrue, valFalse]`	Conditional value (condition from `Conditions`)
`Fn::ImportValue`	`!ImportValue name`	Read another stack’s export
`Fn::Select`	`!Select [0, !GetAZs '']`	Pick item from a list (`!GetAZs` = region’s AZs)
`Fn::Split`	`!Split [',', !Ref Csv]`	String to list
`Fn::FindInMap`	`!FindInMap [Map, Key, SubKey]`	Lookup in `Mappings`

!Sub beats !Join for readability in almost every case:

BucketArn: !Sub 'arn:${AWS::Partition}:s3:::${MyBucket}/*'

Sample Template: S3 + IAM

Docs: AWS::S3::Bucket, CloudFormation User Guide
Explore this further in Docker Cheatsheet

AWSTemplateFormatVersion: '2010-09-09'
Description: Versioned artifact bucket with a scoped writer role

Parameters:
  EnvName: { Type: String, Default: dev }

Conditions:
  IsProd: !Equals [!Ref EnvName, prod]

Resources:
  ArtifactBucket:
    Type: AWS::S3::Bucket
    DeletionPolicy: Retain
    UpdateReplacePolicy: Retain
    Properties:
      BucketName: !Sub 'artifacts-${EnvName}-${AWS::AccountId}'
      VersioningConfiguration:
        Status: !If [IsProd, Enabled, Suspended]
      PublicAccessBlockConfiguration:
        BlockPublicAcls: true
        RestrictPublicBuckets: true

  WriterRole:
    Type: AWS::IAM::Role
    Properties:
      AssumeRolePolicyDocument:
        Version: '2012-10-17'
        Statement:
          - { Effect: Allow, Principal: { Service: ec2.amazonaws.com }, Action: 'sts:AssumeRole' }
      Policies:
        - PolicyName: write-artifacts
          PolicyDocument:
            Version: '2012-10-17'
            Statement:
              - Effect: Allow
                Action: ['s3:PutObject', 's3:GetObject']
                Resource: !Sub '${ArtifactBucket.Arn}/*'

Outputs:
  BucketName:
    Value: !Ref ArtifactBucket
    Export:
      Name: !Sub '${EnvName}-artifact-bucket'

CLI: Deploy & Stack Lifecycle

Docs: cloudformation, AWS CLI Command Reference
Discover related concepts in Python Basics & CLI Cheatsheet

# One command, idempotent - creates or updates (my default)
aws cloudformation deploy \
  --stack-name app-dev \
  --template-file template.yaml \
  --parameter-overrides EnvName=dev VpcCidr=10.1.0.0/16 \
  --capabilities CAPABILITY_NAMED_IAM \
  --no-fail-on-empty-changeset

# Explicit create / update
aws cloudformation create-stack --stack-name app-dev \
  --template-body file://template.yaml \
  --parameters ParameterKey=EnvName,ParameterValue=dev \
  --capabilities CAPABILITY_IAM
aws cloudformation update-stack --stack-name app-dev \
  --template-body file://template.yaml \
  --parameters ParameterKey=EnvName,UsePreviousValue=true

# Wait + inspect
aws cloudformation wait stack-create-complete --stack-name app-dev
aws cloudformation describe-stacks --stack-name app-dev --query 'Stacks[0].Outputs'
aws cloudformation describe-stack-events --stack-name app-dev \
  --query 'StackEvents[?ResourceStatus==`CREATE_FAILED`]'

# Delete
aws cloudformation delete-stack --stack-name app-dev

Change Sets

Docs: Updating stacks using change sets, CloudFormation User Guide

Preview exactly what an update will touch before executing. Mandatory habit for prod:

aws cloudformation create-change-set \
  --stack-name app-prod --change-set-name add-alarms \
  --template-body file://template.yaml \
  --capabilities CAPABILITY_NAMED_IAM

aws cloudformation describe-change-set \
  --stack-name app-prod --change-set-name add-alarms \
  --query 'Changes[].ResourceChange.{Action:Action,Resource:LogicalResourceId,Replacement:Replacement}'

aws cloudformation execute-change-set \
  --stack-name app-prod --change-set-name add-alarms

Replacement: True means the resource gets destroyed and recreated. Check this column every time.

Drift Detection

Docs: Detecting stack drift, CloudFormation User Guide
Journey deeper into this topic with Kubernetes Cheatsheet

aws cloudformation detect-stack-drift --stack-name app-prod
aws cloudformation describe-stack-drift-detection-status --stack-drift-detection-id <id>
aws cloudformation describe-stack-resource-drifts --stack-name app-prod \
  --stack-resource-drift-status-filters MODIFIED DELETED

Stack Policies & Termination Protection

Docs: Stack policies, CloudFormation User Guide

# Termination protection - flip on for anything prod
aws cloudformation update-termination-protection \
  --stack-name app-prod --enable-termination-protection

{
  "Statement": [
    { "Effect": "Allow", "Action": "Update:*", "Principal": "*", "Resource": "*" },
    { "Effect": "Deny",  "Action": ["Update:Replace", "Update:Delete"],
      "Principal": "*", "Resource": "LogicalResourceId/ProdDatabase" }
  ]
}

aws cloudformation set-stack-policy --stack-name app-prod \
  --stack-policy-body file://policy.json

Also set DeletionPolicy: Retain (and UpdateReplacePolicy: Retain) on stateful resources: databases, buckets, EFS.

Nested Stacks & Exports

Docs: Working with nested stacks, CloudFormation User Guide

Resources:
  NetworkStack:
    Type: AWS::CloudFormation::Stack
    Properties:
      TemplateURL: https://s3.amazonaws.com/my-templates/network.yaml
      Parameters:
        EnvName: !Ref EnvName

  App:
    Type: AWS::EC2::Instance
    Properties:
      SubnetId: !GetAtt NetworkStack.Outputs.PublicSubnetId

Cross-stack (not nested): export in one stack’s Outputs, then !ImportValue prod-vpc-id elsewhere. You cannot delete or change an export while another stack imports it. Nested stacks avoid that coupling; exports make it explicit.

Pseudo Parameters

Docs: Pseudo parameters reference, CloudFormation User Guide
Master this concept through Jenkins Cheatsheet

Parameter	Example value
`AWS::AccountId`	`123456789012`
`AWS::Region`	`ca-central-1`
`AWS::StackName`	`app-prod`
`AWS::Partition`	`aws` (or `aws-cn`, `aws-us-gov`)
`AWS::NoValue`	Removes a property when used with `!If`

Validation & Linting

Docs: validate-template, AWS CLI Command Reference

aws cloudformation validate-template --template-body file://template.yaml

pip install cfn-lint
cfn-lint templates/**/*.yaml           # catches type errors, bad refs, region issues

validate-template only checks syntax; cfn-lint checks semantics against the real resource specs. Run both in CI.

Rollback Behavior

Docs: Continue rolling back an update, CloudFormation User Guide
Deepen your understanding in Ansible Cheatsheet
0

Create fails → ROLLBACK_COMPLETE: stack is dead, delete it and recreate.
Update fails → automatic rollback to previous working state (UPDATE_ROLLBACK_COMPLETE); if that rollback fails, continue-update-rollback (optionally --resources-to-skip).
--disable-rollback / --on-failure DO_NOTHING on create keeps failed resources up for debugging.

A stack stuck in ROLLBACK_COMPLETE after a failed create can never be updated, only deleted. Delete it, fix the template, and create again. This surprises everyone exactly once.

Common Errors

Docs: Troubleshooting CloudFormation, CloudFormation User Guide
Deepen your understanding in Ansible Cheatsheet
1

Error	Cause	Fix
`No updates are to be performed`	Template unchanged	Use `deploy` with `--no-fail-on-empty-changeset`
`Requires capabilities: [CAPABILITY_IAM]`	Template creates IAM resources	Add `--capabilities CAPABILITY_IAM` (or `CAPABILITY_NAMED_IAM` for named ones)
`Export ... cannot be deleted as it is in use`	Another stack imports the value	Update/delete importing stacks first
`Resource ... already exists`	Name collision with unmanaged resource	Remove hardcoded name or import the resource (`import` change set type)
`Template format error: Unresolved resource dependencies`	`!Ref`/`!GetAtt` to a typo’d logical ID	Fix the logical ID; `cfn-lint` catches this
Stuck in `UPDATE_ROLLBACK_FAILED`	Rollback blocked (e.g. deleted resource)	`continue-update-rollback --resources-to-skip`
`Rate exceeded`	API throttling on big stacks	Retry with backoff; split mega-stacks into nested stacks
`Circular dependency between resources`	Mutual `!Ref`s (common with SGs)	Split with `AWS::EC2::SecurityGroupIngress` standalone resources

Ansible: configuration management for the instances these stacks provision, with modules, handlers, roles, and Vault
Python Boto3: the imperative side, with clients, paginators, waiters, and ClientError handling for anything a template can’t express
Kubernetes: manifests, rollouts, and kubectl triage for the workloads that land on the clusters these stacks create
