Jenkins Cheatsheet Jenkins Cheatsheet

pipeline {
    agent any
    options {
        timeout(time: 30, unit: 'MINUTES')
        buildDiscarder(logRotator(numToKeepStr: '20'))
        disableConcurrentBuilds()
        timestamps()
    }
    environment {
        APP_ENV = 'staging'
    }
    stages {
        stage('Build') {
            steps {
                sh 'make build'
            }
        }
        stage('Test') {
            steps {
                sh 'make test'
            }
        }
        stage('Deploy') {
            steps {
                sh './deploy.sh'
            }
        }
    }
    post {
        always  { cleanWs() }
        success { echo 'Build passed' }
        failure { mail to: 'team@example.com', subject: "FAILED: ${env.JOB_NAME} #${env.BUILD_NUMBER}", body: "${env.BUILD_URL}" }
    }
}

environment {
    // From Jenkins credentials store (ID must exist)
    AWS_CREDS   = credentials('aws-prod')          // sets AWS_CREDS_USR / AWS_CREDS_PSW
    API_TOKEN   = credentials('api-token-secret')  // secret text -> single var
}

// Scoped binding inside steps - preferred for secrets
steps {
    withCredentials([
        usernamePassword(credentialsId: 'nexus', usernameVariable: 'NEXUS_USER', passwordVariable: 'NEXUS_PASS'),
        string(credentialsId: 'slack-token', variable: 'SLACK_TOKEN'),
        file(credentialsId: 'kubeconfig-prod', variable: 'KUBECONFIG'),
        sshUserPrivateKey(credentialsId: 'deploy-key', keyFileVariable: 'SSH_KEY')
    ]) {
        sh 'curl -u "$NEXUS_USER:$NEXUS_PASS" https://nexus.internal/upload'
    }
}

parameters {
    string(name: 'VERSION', defaultValue: '1.0.0', description: 'Release version')
    choice(name: 'ENV', choices: ['dev', 'staging', 'prod'], description: 'Target environment')
    booleanParam(name: 'SKIP_TESTS', defaultValue: false)
    text(name: 'RELEASE_NOTES', defaultValue: '')
}
// Access: params.VERSION, params.ENV, params.SKIP_TESTS

stage('Deploy Prod') {
    when {
        allOf {
            branch 'main'
            environment name: 'APP_ENV', value: 'prod'
            expression { return params.ENV == 'prod' }
            not { changeRequest() }          // skip on PR builds
        }
    }
    steps { sh './deploy.sh prod' }
}

stage('Quality Gates') {
    parallel {
        stage('Lint')  { steps { sh 'make lint' } }
        stage('Unit')  { steps { sh 'make unit' } }
        stage('Integration') {
            agent { label 'docker' }
            steps { sh 'make integration' }
        }
    }
}
// failFast true  -> abort siblings on first failure (put inside options or parallel)

// Jenkinsfile - library configured globally as "mylib"
@Library('mylib@main') _

standardBuild(language: 'go', notify: '#builds')   // vars/standardBuild.groovy

(root)
├── vars/standardBuild.groovy      # def call(Map config) { ... } - callable as a step
├── src/org/acme/Utils.groovy      # classes, import as org.acme.Utils
└── resources/templates/pod.yaml   # libraryResource 'templates/pod.yaml'

stage('Build')  { steps { sh 'make dist'; stash name: 'dist', includes: 'dist/**' } }
stage('Deploy') { agent { label 'deployer' }
                  steps { unstash 'dist'; sh './push.sh' } }

// Keep artifacts on the build page
archiveArtifacts artifacts: 'dist/*.tar.gz', fingerprint: true, allowEmptyArchive: false
junit 'reports/**/*.xml'

triggers {
    cron('H 2 * * 1-5')          // weeknights, H spreads load
    pollSCM('H/5 * * * *')       // poll every ~5 min
    upstream(upstreamProjects: 'lib-build', threshold: hudson.model.Result.SUCCESS)
}

curl -O https://jenkins.example.com/jnlpJars/jenkins-cli.jar   # from your own controller
alias jcli='java -jar jenkins-cli.jar -s https://jenkins.example.com -auth user:apitoken'

jcli list-jobs
jcli build my-job -p ENV=staging -f -v      # -f wait, -v stream console
jcli console my-job 42                      # console log of build 42
jcli reload-configuration
jcli safe-restart
jcli install-plugin blueocean -deploy

// Capture command output
def sha = sh(script: 'git rev-parse --short HEAD', returnStdout: true).trim()

// Exit code without failing the stage
def rc = sh(script: './smoke-test.sh', returnStatus: true)
if (rc != 0) { unstable('smoke tests failed') }

// JSON in/out (Pipeline Utility Steps plugin)
def cfg = readJSON file: 'config.json'
echo "replicas: ${cfg.deploy.replicas}"
writeJSON file: 'out.json', json: [version: sha, env: params.ENV]

// YAML too
def vals = readYaml file: 'values.yaml'

// Retry and timeout wrappers
retry(3) { sh './flaky-fetch.sh' }
timeout(time: 5, unit: 'MINUTES') { input message: 'Deploy to prod?' }

agent { label 'linux && docker' }        // label expression

agent {
    docker {
        image 'golang:1.22'
        args  '-v /var/cache/go:/go/pkg'
        reuseNode true
    }
}

agent {
    dockerfile { filename 'ci/Dockerfile'; label 'docker' }
}
